Tridon Flex-Gear LD 14mm - 9/16" Perforated 410SS


Tridon Flex-Gear LD 14mm - 9/16" Perforated 410SS
Purchase Tridon Flex-Gear LD 14mm - 9/16" Perforated 410SS

  • Tridon Flex-Gear LD 14mm - 9/16" Perforated 410SS

  • Tridon Flex-Gear LD 14mm - 9/16" Perforated 410S - all stainless steel clamps use a Belleville spring design to eliminate “cold flow” leakage in light duty applications and adjust with the hose and fitting to maintain constant tension on the connection, eliminating leak paths. Flex-Gear clamps are an excellent choice for fluctuating and extreme temperature applications and thermal compensation.

  • Band Material: 300SS, Screw 410SS
  • Band Thickness Max: 0.64
  • Band Width Max (mm): 14.4
  • Screw Head Hex Size (mm): 8
  • Max Recommended Installation Torque (Nm): 5.6
  • Housing Width Max HW (mm): 19.0
  • Housing Height Max HH (mm): 13.0



See more products like this one:

Tridon Flex-Gear LD 14mm - 9/16" Perforated 410SS

Article Number Clamping Range
450020010 14-27
450020012 16-32
450020016 21-38
450020020 20-44
450020024 27-51
450020028 33-57
450020032 40-63
450020036 46-70
450020040 52-76
450020044 59-82
450020048 65-89
